Description
Victron Energy SCC110020160R SmartSolar MPPT 100/20 20A 12/24/48V Charge Controller
Overview
The Victron SmartSolar MPPT 100/20 (SCC110020160R) is a versatile and intelligent solar charge controller engineered for 12V, 24V, and 48V battery systems. With a 20A charging capacity and ultra-fast Maximum Power Point Tracking (MPPT), this unit significantly boosts solar yield—especially in variable weather conditions.
Built-in Bluetooth provides wireless configuration and monitoring via the VictronConnect app. With intelligent load control, programmable charging, and compatibility with lithium and lead-acid batteries, this controller is perfect for a broad range of off-grid and mobile applications.
Key Features
- 12V, 24V, and 48V Auto-Select: Supports a wide range of system voltages without manual switching.
- 20A MPPT Charging: Captures maximum solar power with ultra-fast MPPT tracking, even in shaded or cloudy environments.
- Bluetooth Smart Built-In: Wirelessly monitor and configure via the VictronConnect app.
- Battery Life Algorithm: Extends battery life by intelligently managing state-of-charge.
- Fully Programmable Charge Profiles: Compatible with flooded, AGM, GEL, and lithium-ion batteries.
- Load Output with Protection: Disconnects the load in over-discharge conditions; short-circuit proof.
- VE.Direct Communication Port: Optional connection to GX devices or Color Control GX for VRM Portal access.
- Automatic Recovery for Deep-Discharged Batteries: Reconnects even from 0V on supported chemistries.
Applications
- Off-grid solar cabins and homes
- RV and camper electrical systems
- 48V telecom and industrial battery banks
- Solar lighting and surveillance stations
- Battery maintenance for remote monitoring equipment
Industries & Use Cases
- Off-grid energy solutions
- Remote power for telecom, security, and agriculture
- Marine and mobile power systems
- Solar system integrators and OEMs
- Rural electrification and mini-grid setups
Technical Specifications
| Parameter | Value |
|---|---|
| Battery Voltage | 12V / 24V / 48V (auto select) |
| Rated Charge Current | 20A |
| Nominal PV Power | 290W @ 12V / 580W @ 24V / 1160W @ 48V |
| Max PV Open Circuit Voltage | 100V |
| Max PV Short Circuit Current | 20A |
| Charge Algorithm | Multi-stage adaptive |
| Absorption Voltage | 14.4V / 28.8V / 57.6V (adjustable) |
| Float Voltage | 13.8V / 27.6V / 55.2V (adjustable) |
| Low Voltage Disconnect | 44.4V or 47.2V (48V) / Battery Life algorithm |
| Low Voltage Reconnect | 52.4V or 56V (48V) / Battery Life algorithm |
| Max Continuous Load Current | 20A |
| Efficiency | Up to 98% |
| Operating Temp. Range | -22°F to +140°F (-30°C to +60°C) |
| Dimensions (HxWxD) | 3.9 x 4.4 x 2.4 in (100 x 113 x 60 mm) |
| Weight | 1.43 lbs (0.65 kg) |
| Enclosure Rating | IP43 (electronics), IP22 (connection area) |
| Standards | EN/IEC 62109-1, UL 1741, CSA C22.2 |
Note: The controller can accept more PV wattage than rated but will limit current to 20A for battery safety. Ensure PV voltage and current remain within spec.
Need More Technical Detail?
Need firmware, timing control, or extended diagnostics? Download the official Victron spec sheet here.
Warranty Information
Additional Information
Victron Energy SCC110020160R SmartSolar 20 Amp 12/24/48V MPPT 100/20 Charge Controller: |
