Overview

The MidNite Solar MNEPV 150VDC circuit breaker provides compact DC overcurrent protection for photovoltaic, battery, telecom, UPS, and other DC power systems. This single-pole breaker uses hydraulic-magnetic trip technology, mounts on DIN rail, and is non-polarized for reverse-feed operation. Its compact 13 mm module width helps conserve enclosure space while providing manual switching and electrical isolation capability.

Key Features

  • 150 VDC rating: Designed for DC circuit protection at up to 150 VDC per pole.
  • Non-polarized design: Reverse-feedable for flexible DC system installation.
  • Hydraulic-magnetic operation: Provides 100% rating capability independent of ambient temperature.
  • Compact DIN-rail format: 13 mm module width minimizes required panel and enclosure space.
  • High interrupting capacity: Rated to 10 kA at 150 VDC under UL 489B data.
  • Immediate reset capability: Can be switched on immediately after tripping.
  • Isolation capability: Suitable for electrical isolation with ON/OFF indication.
  • Wide operating range: Rated for ambient temperatures from -40°C to +85°C.

Applications

  • Photovoltaic and solar power equipment
  • DC circuit protection
  • Battery protection
  • Telecom and datacom systems
  • UPS equipment
  • Alternative energy systems

Industries & Use Cases

  • Commercial and industrial solar installations
  • Remote power and battery-based systems
  • Telecommunications and network infrastructure
  • DC distribution and control panels
  • System integration and OEM equipment
  • Backup power and UPS installations

Technical Specifications

Field Value
Product Type Hydraulic-Magnetic DC Circuit Breaker
Number of Poles 1 Pole
Rated Voltage 150 VDC
Polarity Non-Polarized / Reverse-Feedable
Interrupting Capacity 10 kA at 150 VDC (UL 489B data)
Mounting DIN Rail
Module Width 13 mm
Trip Technology Hydraulic-Magnetic
Ambient Operating Temperature -40°C to +85°C
Main Terminal Wire Range 18–6 AWG
IEC Conductor Range 2.5 mm² to 16 mm²
Terminal Torque 30 lbf-in (UL) / 3.5 N·m (IEC)
Rated Impulse Withstand Voltage 4 kV
Shock 20 G
Vibration 3 G
Endurance 10,000 operations per IEC 60947-2 test data
Weight 110 g per pole
Available Verified Current Ratings 5A, 10A, 15A, 20A, 30A, 40A, 50A

B2B Add-On

The MidNite Solar MNEPV 150VDC breaker is well suited for integrators, installers, panel builders, and engineers designing compact DC distribution and protection systems. Its narrow DIN-rail footprint, non-polarized construction, hydraulic-magnetic trip mechanism, and broad operating temperature range make it suitable for commercial solar, remote power, telecom, battery, and industrial DC applications where dependable circuit protection and efficient enclosure utilization are important.
