Description
The Rich Solar ALPHA 1, 12V 100Ah LiFePO4 Lithium Iron Phosphate Battery with internal heat technology and bluetooth connectivity has a much longer cycle life capacity, and is easier to maintain compared to other battery technologies. The LiFePO4 technology has better thermal and chemical stability, which improves battery safety and allows us to pack power in a small and lightweight footprint. Features a 10 Year warranty, internal heating technology and bluetooth connectivity built directly into the battery.
| Battery Specifications | |
| Manufacturer Name: | Rich Solar |
| Nominal Voltage: | 12.8V |
| Nominal Capacity: | 100Ah |
| Nominal Energy: | 1280Wh |
| Cycle Life: | 7000 cycles at 80% DOD |
| Maximum Expansion (Parallel & Series): | 4P4S |
| Charge Specifications | |
| Charge Method: | CC/CV |
| Charge Voltage: | 14.4V + or - 0.2V |
| Recommend Charge Current: | 50A (0.2C) |
| BMS | |
| BMS: | 100A |
| Maximum Continuous Charge Current: | 100A |
| Maximum Continuous Discharge Current: | 100A |
| Maximum Discharge Current 10 Seconds: | 110A |
| Temperature Performance | |
| Charge Temperature: | 32 F to 131 F |
| Discharge Temperature: | -4 F to 140 F |
| Storage Temperature: | 14 F to 113 F |
| Self-Heating | |
| Heating Function: | 100W |
| Internal Heating Starts: | Less than 41F |
| Internal Heating Stops: | Greater than 50F |
| Physical Specifications | |
| Battery Dimensions: | 10.2" L x 6.6" W x 8.3" H |
| Weight: | 24 lb |
| Group Size: | 24 |
| Warranty: | 10 Years |
| Protection Class: | IP65 |
| Certifications: | UL1973, FCC, UN38.3 |
Videos
View AllClose
Additional Information
Rich Solar ALPHA 1, 12V 100Ah LiFePO4 Lithium Battery Specifications: |
