Overview

The Jackery HomePower 3600 Plus is an ultra-high-capacity 3584 Wh LiFePO₄ home backup power station engineered for continuous home, RV, or field operation. Delivering 3600 W rated output (7200 W surge) through a pure sine-wave inverter, it powers major household appliances, RVs, and off-grid systems with professional-grade reliability. Equipped with an Uninterruptible Power Supply (UPS) function that automatically transfers power within 10 ms, the HomePower 3600 Plus ensures your devices stay on during outages. It supports Wi-Fi and Bluetooth connectivity via the Jackery App, parallel operation with a second unit, and expandable battery capacity for extended runtime—all in a durable, wheel-mounted chassis built for mobility and power stability.

Key Features

  • 3584 Wh LiFePO₄ battery designed for 6000 + charge cycles to 70 % capacity for extra-long service life.
  • 3600 W continuous / 7200 W surge pure sine wave AC output safely powers large appliances and tools.
  • Uninterruptible Power Supply (UPS) function switches within 10 ms to maintain operation during outages.
  • Wi-Fi + Bluetooth control via Jackery App for real-time monitoring and mode management.
  • Expandable design supports up to five Jackery Battery Pack 3600 units for higher capacity storage.
  • Parallel capability allows dual-unit operation for up to 7200 W output using the Jackery Connector (sold separately).
  • Quiet Charging Mode reduces noise levels while preserving efficiency in indoor environments.
  • Dual DC8020 inputs accept up to 1000 W combined solar charging with priority solar input logic.
  • Intuitive LCD display with status icons for modes, charging plans, and battery health indicators.

Applications

  • Whole-home backup for refrigerators, furnaces, and medical devices
  • Off-grid living and mobile home power solutions
  • Disaster response and emergency preparedness kits
  • Construction and field operations requiring silent power sources

Industries & Use Cases

  • Residential energy storage & backup systems
  • Renewable energy and off-grid solar integration
  • Commercial field operations and remote infrastructure
  • Recreation, RV, and mobile work applications

Technical Specifications

Model Jackery HomePower 3600 Plus (JHP-3600A)
Battery Capacity 3584 Wh (80 Ah @ 44.8 V DC)
Battery Type LiFePO₄ (Lithium Iron Phosphate)
Cycle Life 6000 cycles to 70 % capacity
AC Output 120 V ~ 60 Hz 3600 W (7200 W Surge)
AC Outlets 4 × 120 V (20 A) | 1 × NEMA TT-30 (30 A)
AC Input 100–120 V ~ 60 Hz 15 A Max | Bypass Mode 12 A Max (1440 W)
USB-C Outputs 2 × 100 W PD (5 – 20 V ⎓ 5 A Max)
USB-A Outputs 2 × 18 W (QC 3.0)
Car Port Output 12 V ⎓ 10 A (120 W Max)
DC Input / Solar Input 2 × DC8020 Ports (16–60 V ⎓ 12 A each / 1000 W Max combined)
Parallel Capability Supports AC Parallel Connection (up to 7200 W using Jackery Connector)
Operating Temperature –4 °F to 113 °F (–20 °C to 45 °C)
UPS Transfer Time ≤ 10 ms
Connectivity Wi-Fi + Bluetooth (Jackery App Control)
Weight 77.2 lb (35 kg)
Dimensions (W × D × H) 15.2 × 12.2 × 19.3 in (38.5 × 30.9 × 49.1 cm)
Certifications FCC / UL / UN38.3 / RoHS
Warranty 3 Years Standard + 2 Years Extended (with registration)

B2B Add-On

Integrate the Jackery HomePower 3600 Plus into your residential solar or commercial fleet applications. Contact our B2B sales team for custom integration data, OEM collaboration, and bulk order support.
